500m Output Distance 4m Dredging Depth Amphibious Excavator with 1m³ Bucket Capacity

Qingzhou Keda Mining Machine co.,Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

500m Output Distance 4m Dredging Depth Amphibious Excavator with 1m³ Bucket Capacity

Place of Origin : Shandong china

Brand Name : Keda

Price : $24,000/sets >=1 sets

Video outgoing-inspection : Provided

Machinery Test Report : Provided

Core Components : Engine, Gearbox, Motor, Bearing

Working Capacity : 500m³/h

Type : Amphibious dredger

Power Type : Diesel

Dredging Depth : 4 m

Draught : 1 inch

Dimension(L*W*H) : 10*3.9*3.5

Weight : 20000 KG

Warranty : 1 Year

Bucket Capacity : 1m3

Water Flow : 500m3

Total Power : 194kw

Total Length of Digging Arm : 10m

Diesel Engine Power : 194kw

Output Distance : 500m

Water Flow of Suction Pump : 500m3/h

Lift head : 50m

Cutter Head Dia. : 700mm

Total Length of SPUD : 8m

Certification : CE 9001

MOQ : 1

Contact Now

Product Description
500m Output Distance 4m Dredging Depth Amphibious Excavator with 1m³ Bucket Capacity
Keda Custom Amphibious Excavator

This product is a multi-purpose excavator suitable for land, swamp soft ground and shallow water working environment. The walking device adopts a multihull pontoon structure and a sealed box-shaped track shoe, which can safely walk and work on silt and water.

The front head can replace the gun head, reamer head, bucket and other devices to ensure the quality of work and the efficiency of digging, and improve the convenience and comfort of operation. The scientific and reasonable matching of the advanced hydraulic system and the power system device can easily realize the compound operation action and ensure the unity of high efficiency and high economy.

500m Output Distance 4m Dredging Depth Amphibious Excavator with 1m³ Bucket Capacity
500m Output Distance 4m Dredging Depth Amphibious Excavator with 1m³ Bucket Capacity
500m Output Distance 4m Dredging Depth Amphibious Excavator with 1m³ Bucket Capacity
500m Output Distance 4m Dredging Depth Amphibious Excavator with 1m³ Bucket Capacity
500m Output Distance 4m Dredging Depth Amphibious Excavator with 1m³ Bucket Capacity
Product parameters
Main Engine
Power
150kw
Displacement
6.7L
Cylinder
6 pieces
Fuel Tank
400L
Hydraulic Tank
220L
Main Pontoon
Dimensions for one buoyancy
8.5*15*1.9m
Overall width of chassis
4.6m
Number of chains on each buoyancy tank
2 rows
Chain rail material
high-strength steel (785)
Paint
marine e anti-corrosion
Side Pontoon with SPUD
Dimensions for one buoyancy
7.5*1.5*1.1m
SPUD Length
6m
System
Full -hydraulic
Motor
Volvo 250
1 pair
Other parts
Arm

Basket Capacity
0.8m³
Hydro-cylinder
4 pieces
Details Images
500m Output Distance 4m Dredging Depth Amphibious Excavator with 1m³ Bucket Capacity
500m Output Distance 4m Dredging Depth Amphibious Excavator with 1m³ Bucket Capacity
500m Output Distance 4m Dredging Depth Amphibious Excavator with 1m³ Bucket Capacity
Company Profile
Qingzhou Keda Environment Protection Machinery Co., Ltd.

Qingzhou Keda Environment Protection Machinery Co., Ltd.
Located in Qingzhou City, Shandong Province, is a high-tech enterprise with over 30 national patents focusing on the designing, manufacturing, assembly and operation management of environmental protection projects and equipment with more than 11 years′ designing and manufacturing experience.

In the two fields of manufacturing and service providing of waters environmental protection equipment, KEDA is engaged in three industries including the research, development and manufacturing, the equipment assembly and commissioning, and the marketing and after-sales service. KEDA products have been exported to more than 50 countries and areas in Southesat Asia, East Asia, Sout Asia, South America, Oceania, Africa and East Europe, such as United States, Russia, Indonesia, North Korea, the Philippines, Cambodia, Myanmar, Kyrgyzstanm, Kazakhstan, Brazil, Guyana, Suriname, Congo, Ghana, Nigeria, Zimbabwe, etc.

The products have gained recognition and support from customers both at home and abroad due to KEDA′s leading industry technology,professional manufacturing experience, excellent equipment quality and integrity in management.

KEDA will continue to do the best to create world famous brand in the field of waters environmental protection. Welcome to KEDA for investigation, visit and technique communication.

Video content will be displayed here.

Certifications
500m Output Distance 4m Dredging Depth Amphibious Excavator with 1m³ Bucket Capacity
Our Cases
500m Output Distance 4m Dredging Depth Amphibious Excavator with 1m³ Bucket Capacity
FAQ

1. who are we?
We are a based in Shandong, China, start from 2011. There are total about 51-100 people in our office.We are a professional manufacturer of aquatic and amphibious equipment. The main equipment we produce and design are dredgers,amphibious excavators, aquatic weed harvester and gold panning equipment.

2. How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.What can you buy from us?
Dredger,Gold mining equipment,Water weed harvester,Sand production equipment

4. Why should you buy from us not from other suppliers?
We are specialized in mineral processing equipment,exported to all over the world,had got the patent about gold washing
equipment.Combined with research and development, engineering design, producing,installation and commissioning and after sale service.

5. What services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,CIP;
Accepted Payment Currency:USD,EUR;

Accepted Payment Type: T/T,L/C,Credit Card,Western Union,Cash;
Language Spoken:English,Chinese
